Mitsubishi Electric MELSEC-Q00U(J)CPU

480
(8) Common processing time
The CPU module performs common processing by the system. The common processing time shown below is
required.
*1 At default setting of parameters, and including processing time for latching 8K points of latch relay (L).
(9) Multiple CPU high speed transmission processing time
This is the processing time required for data transmission between the CPU modules when the multiple CPU high
speed transmission function is used.
For the multiple CPU high speed transmission processing time, refer to the following.
QCPU User's Manual (Multiple CPU System)
CPU module Processing time
Q00UJCPU, Q00UCPU, Q01UCPU 0.28ms
Q02UCPU 0.20ms
Q03UDCPU 0.13ms
Q04UDHCPU, Q06UDHCPU, Q10UDHCPU, Q13UDHCPU,
Q20UDHCPU, Q26UDHCPU
0.10ms
Q03UDECPU 0.22ms
Q04UDEHCPU, Q06UDEHCPU, Q10UDEHCPU, Q13UDEHCPU,
Q20UDEHCPU, Q26UDEHCPU, Q50UDEHCPU, Q100UDEHCPU
0.18ms
Q03UDVCPU
0.140ms
*1
Q04UDVCPU, Q04UDPVCPU, Q06UDVCPU, Q06UDPVCPU,
Q13UDVCPU, Q13UDPVCPU, Q26UDVCPU, Q26UDPVCPU
0.125ms
*1
