486
(7) Online change
When data is written to the running CPU module, the processing time described below is required.
(a) Online change (ladder mode)
When a program in the running CPU module is changed in ladder mode, the processing time listed in the
following table is required.
*1
*1 The time in the table is for the case where the service processing count is set to one.
CPU module
Reserved area for online change
The reserved area for online
change is not changed.
The reserved area for online
change is re-set.
Q00UJCPU, Q00UCPU, Q01UCPU Up to 2.1ms Up to 2.1ms
Q02UCPU Up to 1.3ms Up to 1.3ms
Q03UD(E)CPU Up to 1.0ms Up to 1.0ms
Q04UD(E)HCPU, Q06UD(E)HCPU, Q10UD(E)HCPU,
Q13UD(E)HCPU, Q20UD(E)HCPU, Q26UD(E)HCPU,
Q50UDEHCPU, Q100UDEHCPU
Up to 0.7ms Up to 0.7ms
Q03UDVCPU, Q04UDVCPU, Q04UDPVCPU,
Q06UDVCPU, Q06UDPVCPU, Q13UDVCPU,
Q13UDPVCPU, Q26UDVCPU, Q26UDPVCPU
Up to 0.6ms Up to 0.6ms
