1.2 Features
(1) Flexible system configuration
The employed connection block type provides the combined use of a main module and an extension module.
A flexible configuration can be achieved because various extension modules can be connected.
In addition, the main module always monitors the connection status of the extension module, leading to an early
detection of connection failure.
(2) Easy setting of station numbers
Station numbers are set with the rotary switch on the front of the module, where setting and checking the station
numbers are easy.
(3) Selectable conversion speed
A/D conversion at 100μs/channel meets the need of a high-speed conversion.
Under the environment in which noise is likely to occur, switching the conversion speed to 400μs/channel or
1ms/channel minimizes the effect of noise on the digital operation value, the stability of which is improved.
The flexible combination is possible.
Extension output module (sink type)
Extension output module (source type)
Extension input module
Various extension modules can be
connected according to the application.
No wiring of wires and Ethernet cables
is required.
Extension moduleMain module
Main A/D converter module
Extension A/D converter module
Extension D/A converter module
