3 SPECIFICATIONS
3.2 Performance Specifications
■Terminal block for input
Pin number Signal name Pin number Signal name
1X017X8
2 COM B 18 COM B
3X119X9
4 COM B 20 COM B
5X221XA
6 COM B 22 COM B
7X323XB
8 COM B 24 COM B
9X425XC
10 COM B 26 COM B
11 X5 27 XD
12 COM B 28 COM B
13 X6 29 XE
14 COM B 30 COM B
15 X7 31 XF
16 COM B 32 COM B
 33 COM A
34 COM B
13579111315171921232527293133
246810121416182022242628303234

Mitsubishi Electric NZ2MFB2-16A Specifications

General

Brand	Mitsubishi Electric
Model	NZ2MFB2-16A
Category	Controller
Language	English
