6.4 Output Mode at Operating Status Change (STOP to RUN)
(5) Precautions
Table6.5 shows the output status of the CPU module when the operating status is changed from STOP to RUN
after the outputs (Y) are forcibly turned on in the STOP status.
Table6.5 Output status when the operating status is changed from STOP to RUN after the output forced on operation is
performed
Output mode ("Output mode at STOP to RUN")
selected
Output status
Previous state
The output status prior to STOP is output.
Even if the outputs are forcibly turned on, the on status is not
held if the output status prior to STOP was off.
Recalculate (output is 1 scan later) The on status is held and output.
