Mitsubishi AL2 Series User Manual

α2 Simple Application Controllers
Function Blocks 6
6 - 55
6.26 Calculation Block
The function block creates an expression using up to four input word data (A, B, C and D)
using five operators (+, -, * , /, %) and outputs the calculation result to Y. A maximum of 64
terms can be included in the calculation expression. Nesting using parenthesis is available up
to 6 times.
Table 6.26: Calculation Function Block
Table 6.26.1: Calculation Function Block terms
Function Set Item Description
7 I Input pin for multiplication function block
FB
This function block creates an expression using up to 4 input words
(A, B, C, D), 5 operators (+, /, ∗, /, %) and outputs the calculation
result to Y. A maximum of 64 terms can be included in the calculation
expression. Nesting using parenthesis is available up to a maximum
of 6 levels.
Input values A, B, C, and D set the following values
- Constant value (Setting range:-32768 to 32767
- Analog value
- FB value
Output
1) Word Output (Y)
When the input pin is ON, Q=A/B, R=A%B and the word output will
be given the result. When the input pin is OFF the expression is not
executed and the Q and R values will retain the last result.
2) Bit Output
- Operation result Y<-32768: Output pin is turned ON and the
Quotient (Q) will be set to -32768.
- Operation result Y>32767: Output pin is turned ON and the
Quotient (Q) will be set to 32767.
- The divisor is 0: Output pin is turned ON and the Quotient (Q) will
be reset to 0
Term Description
Y Operation result
A, B, C and D Input value
+ Calculation sign for addition
- Calculation sign for subtraction
∗ Calculation sign for multiplication
/ Calculation sign to request the Quotient
% Calculation sign to request the reminder
000
AC
OI
L
P

Mitsubishi AL2 Series Specifications

General

Model	AL2 Series
Digital Inputs	Yes
Digital Outputs	Yes
Type	PLC
Manufacturer	Mitsubishi
Input Voltage	100 to 240 VAC or 24 VDC (depending on model)
Output Voltage	24V DC
Number of Inputs	8 to 64 (depending on model)
Number of Outputs	6 to 64 (depending on model)
Programming Language	Ladder Diagram
Communication Ports	RS-232, RS-485, Ethernet (depending on model)
Operating Temperature	0 to +55°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Weight	Varies depending on the model
