F940GOT Handy Series Specifications 2
2-3
2.2 Power Supply Specifications
2.3 General Specifications
Table 2.1: Power Supply Specifications
Items Specifications
Power Supply Voltage 24V DC, +10% -15%
Power Supply Ripple 200 mV or less
Current Consumption
Ratings: 300 mA at 24V DC
(200 mA at 24V DC when backlight is turned OFF)
Fuse 1.0 A built-in fuse (impossible to change)
Max. Allowable
Momentary Power
Supply Failure period
5 ms; If less than 5 ms, the Handy GOT will continue operation. If 5 ms or
more, the Handy GOT will shut down.
Battery
Built-in, FX
2NC
-32BL type lithium battery. (Approximately 3 years life)
Guaranteed term is 1 year.
Table 2.2: General Specifications
Item Specifications
Operating Temperature 0 ~ 40 °C (32 ~ 104 °F)
Storage Temperature -20 ~ 60 °C (-4 ~ 140 °F)
Humidity 35 ~ 85% Relative Humidity, No condensation
Vibration Resistance
- intermittent vibration
Conforms to IEC 1131-2; 10 ~ 57 Hz: 0.075 mm Half Amplitude
57 ~ 150 Hz: 9.8 m/s
2
Acceleration
Sweep Count for X, Y, Z: 10 times (80 min. in each direction)
Vibration Resistance
- Continuous vibration
Conforms to IEC 1131-2; 10 ~ 57 Hz: 0.035 mm Half Amplitude
57 ~ 150 Hz: 4.9 m/s
2
Acceleration
Sweep Count for X, Y, Z: 10 times (80 min. in each direction)
Shock Resistance
Conforms to IEC 1131-2: 147m/s
2
Acceleration,
3 times in each direction X, Y, and Z
Noise Immunity 1000 Vp-p, 1micro second, 30 ~ 100 Hz, tested by noise simulator
Dielectric Withstand
Voltage
500 V AC > 1 min., tested between power terminals and ground
Insulation Resistance 5 M
Ω
> at 500 V DC, tested between power terminals and ground
Ground Grounding register 100
Ω
or less (Class D)
Protection IP 54
