F940GOT Handy Series Installation 3
3-12
3.4.3 Pin Outs for Relay Cables
1) F9GT-HCAB2-150 relay cable for FX Series (FX
0
, FX
0S
, FX
0N
, FX
1S
, FX
1N
, FX
2N
, FX
2NC
)
PLC
2) F9GT-HCAB3-150 relay cable for FX (FX, FX
2C
), A, QnA series PLC
3) F9GT-HCAB5-150 relay cable for Q series PLC
Table 3.7:
Model Name Length Applicable
F9GT-HCAB2-150
1.5m (4' 11")
FX Series (FX
0
, FX
0S
, FX
0N
, FX
1S
, FX
1N
, FX
2N
, FX
2NC
)
F9GT-HCAB3-150 FX (FX, FX
2C
), A, QnA Series
To the pow er supply and operation sw itches.
A nam e label is attached to the tip of each
untied w ire.
To FX series P LC (8-pin M IN I-D IN connector)
C onnected
external
cable
25pin D -sub fem ale
connector
(panel face
m ounting type)
1.5m (4' 11")
0.5m (1' 7")
For ground
(grounding resistance 100
9
or less, class D )
1.5m (4' 11")
0.5m (1' 7")
C onnected
external
cable
25pin D -sub fem ale
connector
(panel face
m ounting type)
To the pow er supply and operation sw itches.
A nam e label is attached to the tip of each
untied w ire.
To FX (25pin D -sub connector), A and Q nA
series P LC
For ground
(grounding resistance 100
9
o r le s s , c la s s D )
1.5m (4' 11")
0.5m (1' 7")
C onnected
external
cable
25pin D -sub fem ale
connector
(panel face
m ounting type)
To the pow er supply and operation sw itches.
A nam e label is attached to the tip of each
untied w ire.
For ground
(grounding resistance 100
9
or less, class D )
To Q series P LC (6-pin M IN I-D IN connector)
