F940GOT Handy Series Preparation of the Operation Switch Name Sheet 4
4-2
4.2 Attachment of sheet
1) Remove the operation switch cover
Insert a screwdriver into the gap *1 or *3
between the operation switch cover and the main
unit, then slowly push the operation switch cover
up.
When either side *1 or *3 comes off, pull the
operation switch cover in the sliding direction to
remove it.
2) Insert the sheet
Insert the name sheet into the following position.
3) Attach the operation switch cover
Align the operation switch cover with the
protrusion *1 or *3 shown in the figure in the step
1), then attach the operation switch cover while
flexing it slightly.
O peration sw itch
cover
*1
*2
*3
S c re w d riv e r
O peration sw itch
cover
Sliding direction
*2
*3
*1
Name sheet insertion slot
*1
*3
L e t it b e s lig h tly w a r p e d .
