F940GOT Handy Series Specifications 2
2-4
2.4 Screen Hardware Specifications
2.5 Emergency and Operation Switch Specifications
Table 2.3: Screen Hardware Specifications
Items F94*GOT-SWD-E F94*GOT-LWD-E
Display Device STN color liquid crystal display
Resolution 320
×
240 (dot), 40 characters
×
15 lines
Dot Pitch 0.36 mm (0.014") Horizontal
×
0.36 mm (0.014") Vertical.
Effective Display Size 115 mm (4.53")
×
86 mm (3.39"); 6 (5.7 inch) type
Number of Colors 8 colors White and Black
Life of liquid crystal
Approximately 50,000 hours (Operating temperature: 25 °C / 77 °F)
Guaranteed term is 1 year.
Backlight Cold cathode tube
Life of Backlight
40,000 hours or more (Operating temperature: 25 °C / 77 °F)
Guaranteed term is 1 year.
Touch Keys Maximum 50 touch keys / screen, 20
×
12 matrix
Interface
With PLC
F940GOT-*DB-H-E: RS-422
F943GOT-*DB-H-E: RS-232C
With
personal
computer
RS-232C
Number of Screens
User screen: 500 screens or less
System screen: Allocated screens No. 1001-1030.
User Memory Flash memory 512 KB (built-in)
Table 2.4: Emergency and Operation Switch Specifications
Item Description
Operation switch
a-contact
×
4 points, 10 mA/24V DC
(Operation life time: appraxinately1,000,000 times)
Emergency stop switch
b-contact
×
1 point, 1 A/24V DC, independent wiring
(AH165-VR01 manufactured by Fuji Electric)
