REASSEMBLY OF BASIC ENGINE
7-14
2.14 Installing gear pump housing
(1)
Install the gear pump housing to the stud bolts on the
gear case.
(2) Tighten the gear pump housing bolt.
(3) Install the last stud bolt to the gear pump housing.
Installing gear pump housing
2.15 Installing tappet
Coat the periphery of tappets with engine oil, insert them
into the tappet holes and place them gently on the
camshafts.
Inserting tappet
Stud (M81.25 mm-15 mm)
Bolt
Gear pump
housing
Apply engine oil.
