COOLING SYSTEM
10-2
1.
Removing cooling system
1.1
Removing cooling fan, fan pulley
, V
-belt, thermost
at, thermoswitch
and water pump
Removing cooling fan, fan pulley
, V
-belt, thermostat, thermoswitch
and water pump
Removing sequence
1
Fan
4
V-belt
7
Pipe
2
Fan spacer
5
Thermostat case
8
Water pump
3
Fan pu
lley
6
Thermoswitch
2
1
3
4
8
Replace
7
5
6
Replace
Replace
157
159
