REASSEMBLY OF BASIC ENGINE
7-15
3. Reassembling flywheel
3.1 Installing oil seal case
&$87,21
Be careful not to damage the oil seal.
(1) Install the new oil seal gasket.
(2) After applying engine oil to the entire circumference of
the oil seal lips, install the oil seal case on the cylinder
block.
Installing oil seal case
3.2 Installing flywheel housing
(1)
Clean the mounting surface of the gasket.
(2) Apply sealant to the gasket to prevent it from falling
off.
(3) Install the gasket.
(4) Install the flywheel housing, aligning its dowel pin
holes and dowel pins, and tighten the bolts.
Note: When the dowel pins are worn or when the flywheel
housing is replaced, replace the dowel pins with new
ones.
Installing flywheel housing
Oil seal case
To Next Page
