FUEL SYSTEM
8-8
2.
Disassembling, inspecting an
d reassemb
ling fuel system
2.1
Disassembling and inspec
ting fuel
injection nozzles
Disassembling and inspecting fuel injection nozzles
Disassembling sequence
1
Nozzle retain
ing nut
4
Pin
7
Nozzle holder
2
Nozzle tip assembly
5
Spring
3
Piece
6
Washer
7
6
5
4
3
2
1
Wea
r
Fatigue and perpendicularity
Wear and damage
Carbon deposit,
clogged injection
nozzle tip
121
123
