SERVICE DATA
2-8
Starter
M002T66071
(24V - 3.2kW)
Pinion shaft end play
0.5
[0.0197]
Pinion gap
0.5 to 2.0
[0.0197 to 0.0787]
Brush length
18
[0.709]
11
[0.4331]
Brush spring load
34 N
{3.47 kgf}
[2 lbf]
28.9 to 39.1 N
{2.95 to 3.99 kgf}
[6.5035 to 8.7963 lbf]
20 N
{2.04 kgf}
[4.4974 lbf]
Commutator radial runout
0.03
[0.0012]
0.10
[0.0039]
Commutator outside diameter
ø 32.0
[1.2598]
ø 31.4
[1.2362]
Depth of undercuts between segments
0.5
[0.020]
0.4 to 0.6
[0.0158 to 0.0236]
0.2
[0.0079] or less
No-load
characteristics
Terminal voltage
23 V
Current
80 A or less
Rotation speed
3400 min
-1
or more
Alternator
A007TA0171B
(12V - 40A)
Brush spring load
4.8 to 6.0 N
{0.49 to 0.61 kgf}
[1.1 to 1.3 lbf]
2.2 N
{0.22 kgf}
[0.5 lbf]
Brush length
18.5
[0.7283]
5.0
[0.197]
Resistance between slip rings
2.95 Ω 2.7 to 3.2 Ω
Slip ring outside diameter
ø 22.7
[0.8937]
ø 22.1
[0.8701]
Output charac-
teristics
(when hot)
2500 min
-1
Terminal
voltage
13.5 V
Current
21 A or more
5000 min
-1
Terminal
voltage
13.5 V
Current
37 A or more
IC regulator adjusting voltage
(at 20°C [68°F] )
14.7 ± 0.3 V
Alternator
A007TA8271A
(24V - 25A)
Brush spring load
4.8 to 6.0 N
{0.49 to 0.61 kgf}
[1.1 to 1.3 lbf]
2.2 N
{0.22 kgf}
[0.5 lbf]
Brush length
18.5
[0.7283]
5.0
[0.197]
Resistance between slip rings
12.4 Ω 11.4 to 13.4 Ω
Slip ring outside diameter
ø 22.7
[0.8937]
ø 22.1
[0.8701]
Output
characteristics
(when hot)
2500 min
-1
Terminal
voltage
27.0 V
Current
18 A or more
5000 min
-1
Terminal
voltage
27.0 V
Current
22 A or more
IC regulator adjusting voltage
(at 20°C [68°F] )
28.5 ± 0.5V
Table 2-7 Maintenance service data table - Electrical system(2 / 3) Unit: mm [in.]
Inspection point Nominal Standard Limit Remark
