Mitsubishi Lancer Evolution IX 2005 User Manual

3-159
CIRCUIT DIAGRAMS - EQUIPMENT
Input signals
•Air flow sensor
•Vehicle speed sensor
• Coolant temperature sensor
• Throttle position sensor
Engine ECU
Front ECU
(tail light relay)
Dedicated fuse
Tail lights, position
lights, licence plate
lights, lighting monitor
warning buzzer
Tail lights, position
lights, licence plate
lights, lighting monitor
warning buzzer
Intercooler
water spray
