3-63

CIRCUIT DIAGRAMS - SIGNALS

Ignition switch (IG1)

Turn signal

light switch

Column switch

Diagnosis connector

J/B side connector

Fusible link

Note :

*3:

• ABS

• ACD, AYC

• ACD (vehicle w/out AYC)

• SRS airbags, seatbelt pre-

tensioners

• Intercooler water spray

•Windscreen washer / wiper

•Warning lights

• Engine control

• Needle meters

• Charging

•Electric stowable remote

control door mirrors

•Generic spare connector

•Cabin lights, boot

compartment lights, ignition

key cylinder illumination light,

door ajar indicator light

(

)

Power

supply
