3-76
CIRCUIT DIAGRAMS - DOOR OPENING / CLOSING CONTROL
Power windows (cont’d)
Power window
main switch
Power window
relay
Power window
sub-switch
(rear : RH)
Power window
motor
(rear : RH)
Hall IC
Hall IC
