CIRCUIT DIAGRAMS - J/B
3-5
Note : The triangle symbols in the J/B and relay boxes show the positions that coincide with the triangle marks engraved
on the relays.
Front side
Rear side
To instrument panel
Power window relay
Fuel pump relay 1
Intercooler water
spray relay
Fuel pump relay 2
Dummy connector
Dummy connector
To roof harness
To instrument panel
Blower relay
Demister relay
Generic fuses
To floor harness (RH)
