M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
90
IB-1501269-J
(1) CG31 (Machine signal input)
Digital input 32 points (1st station)
(3) CG33 (Machine signal input)
Digital input 32 points (2nd station)
(5) CG35 (Machine signal input)
Digital input 32 points (3rd station)
The input/output assignment is modifiable using a parameter. Refer to "17.6.4.2 Arbitrary Device Assignment"
for details.
<Cable side connector type>
Connector : XG4M-4030 / 7940-6500SC
Strain relief : XG4T-4004 / 3448-7940
Recommended manufacturer : OMRON / 3M
CAUTION
Do not apply any voltage to the connectors other than voltage specified in this manual. Failure to observe this
could cause bursting, damage, etc.
Connect the cables to the designated connectors. Incorrect connections could damage the device.
12V, 5V, and 3.3V output from connectors are to supply the power for dedicated peripheral devices. Do not
use for other equipment to supply the power since we do not guarantee the NC operation by voltage down or
noise sneaking.
CG31 CG33 CG35
BA BA BA
20 I X200 20 I X210 20 I X220 20 I X230 20 I X240 20 I X250
19 I X201 19 I X211 19 I X221 19 I X231 19 I X241 19 I X251
18 I X202 18 I X212 18 I X222 18 I X232 18 I X242 18 I X252
17 I X203 17 I X213 17 I X223 17 I X233 17 I X243 17 I X253
16 I X204 16 I X214 16 I X224 16 I X234 16 I X244 16 I X254
15 I X205 15 I X215 15 I X225 15 I X235 15 I X245 15 I X255
14 I X206 14 I X216 14 I X226 14 I X236 14 I X246 14 I X256
13 I X207 13 I X217 13 I X227 13 I X237 13 I X247 13 I X257
12 I X208 12 I X218 12 I
X228 12 I X238 12 I X248 12 I X258
11 I X209 11 I X219 11 I X229 11 I X239 11 I X249 11 I X259
10 I X20A 10 I X21A 10 I X22A 10 I X23A 10 I X24A 10 I X25A
9 I X20B 9 I X21B 9 I X22B 9 I X23B 9 I X24B 9 I X25B
8 I X20C 8 I X21C 8 I X22C 8 I X23C 8 I X24C 8 I X25C
7 I X20D 7 I X21D 7 I X22D 7 I X23D 7 I X24D 7 I X25D
6 I X20E 6 I X21E 6 I X22E 6 I X23E 6 I X24E 6 I X25E
5 I X20F 5 I X21F 5 I X22F 5 I X23F 5 I X24F 5 I X25F
4 NC 4 NC 4 NC 4 NC 4 NC 4 NC
3 DI
COM 3 DICOM 3 DICOM 3 DICOM 3 DICOM 3 DICOM
2 +24V 2 0V 2 +24V 2 0V 2 +24V 2 0V
1 +24V 1 0V 1 +24V 1 0V 1 +24V 1 0V
B1 B20
A1 A20
