M800S/M80/E80 Series Connection and Setup Manual

4 General Specifications

IB-1501269-J

(a) Outline of digital signal input circuit

Both 24V common and 0V common connections are allowed in the digital signal input circuit.

Follow the wiring diagram below for each type.

Input circuit

[FCU8-DX731 / FCU8-DX750 / FCU8-DX760 / FCU8-DX761]

[FCU8-DX834]

X200

X21F

3.3kΩ

DICOM

3.3kΩ

DICOM

CG31/CG35CG31/CG35

X240

X25F

X200

X21F

X240

X25F

24VDC(+)

24V common

Control

circuit

Stabilized

power supply

External contact

24VDC(+)

0V common

Stabilized

power supply

External contact

Control

circuit

X200

X23F

5kΩ

DICOM

X200

X23F

5kΩ

DICOM

24VDC(+)

24V common

Control

circuit

Stabilized

power supply

External contact

24VDC(+)

0V common

Stabilized

power supply

External contact

Control

circuit

CG31/CG33CG31/CG33
