M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
120
IB-1501269-J
(1) CJ31 (Machine signal input)
(3) CJ33 (Machine signal input)
<Cable side connector type>
Connector : XG4M-4030 / 7940-6500SC
Strain relief : XG4T-4004 / 3448-7940
Recommended manufacturer : OMRON / 3M
CAUTION
Do not apply any voltage to the connectors other than voltage specified in this manual. Failure to observe this
could cause bursting, damage, etc.
Connect the cables to the designated connectors. Incorrect connections could damage the device.
12V, 5V, and 3.3V output from connectors are to supply the power for dedicated peripheral devices. Do not
use for other equipment to supply the power since we do not guarantee the NC operation by voltage down or
noise sneaking.
CJ31 CJ33
BA BA
20 IX00 20 IX10 20 IX20 20 IX30
19 IX01 19 IX11 19 IX21 19 IX31
18 IX02 18 IX12 18 IX22 18 IX32
17 IX03 17 IX13 17 IX23 17 IX33
16 IX04 16 IX14 16 IX24 16 IX34
15 IX05 15 IX15 15 IX25 15 IX35
14 IX06 14 IX16 14 IX26 14 IX36
13 IX07 13 IX17 13 IX27 13 IX37
12 IX08 12 IX18 12 IX28 12 IX38
11 IX09 11 IX19 11 IX29 11 IX39
10 IX0A 10 IX1A 10 IX2A 10 IX3A
9 IX0B 9 IX1B 9 IX2B 9 IX3B
8 IX0C 8 IX1C 8 IX
2C 8 IX3C
7 IX0D 7 IX1D 7 IX2D 7 IX3D
6 IX0E 6 IX1E 6 IX2E 6 IX3E
5 IX0F 5 IX1F 5 IX2F 5 IX3F
4 NC 4 NC 4 NC 4 NC
3 DICOM 3 DICOM 3 DICOM 3 DICOM
2 +24V 2 0V 2 +24V 2 0V
1 +24V 1 0V 1 +24V 1 0V
To Next Page
