M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
154
IB-1501269-J
[Connector]
(1) CCL (CC-Link communication)
<Cable side connector type>
Connector : 35505-6000-BOM GF
Recommended manufacturer : 3M
No.
Connector
name
Function
(1) CCL CC-Link communication
CAUTION
Do not apply any voltage to the connectors other than voltage specified in this manual. Failure to observe this
could cause bursting, damage, etc.
Connect the cables to the designated connectors. Incorrect connections could damage the device.
1 I/O DA
2 I/O DB
3 DG
4 NC
5 SLD
(1)
15
1
2
