SIN, SINP
7.12 Special function instructions
: Angle data of which the SIN (sine) value is obtained or head number of the devices where the angle data is stored (real number)
: Head number of the devices where the operation result will be stored (real number)
*1: Applicable for the Universal model QCPU, LCPU.
Function
(1) Returns the SIN (sine) value of the angle designated at and stores the operation result in the device number
designated at .
(2) Angles designated at are set in radian units (degrees / 180).
For conversion between degrees and radian values, see the RAD and DEG instructions.
Operation Error
(1) In any of the following cases, an operation error occurs, the error flag (SM0) turns ON, and an error code is stored into
SD0.
*2: There are CPU modules that will not result in an operation error if -0 is specified.
For details, refer to Page 88, Section 3.2.4.
7.12.1 SIN, SINP SIN operation on floating-po int data (Single pr ecision)
7.12.1 SIN, SINP
• Basic model QCPU: The serial number (first five digits) is
"04122" or later.
Setting
Data
Internal Devices
R, ZR
J\
U\G
Zn
Constants
E
Other
Bit Word Bit Word
–– ––
*1
––
–– ––
*1
–– ––
Error
code
Error details
Q00J/
Q00/
Q01
QnH QnPH QnPRH QnU LCPU
4100
The specified device value is -0.
*2
–– ––
4140
The specified device value is -0, unnormalized number, nonnumeric,
and ± .
–– –– –– ––
4141
The operation result exceeds the following range (when an overflow
occurs):
2
128
| Operation result |
–– –– –– ––
Basic
Process
High
performance
Redundant Universal LCPU
Ver.
Command
Command
SINP
SIN
SINP
SIN S D
S D
S
D
S
D
S
D
+1
32-bit floating-point
real number
SIN (
)
+1
32-bit floating-point
real number
S
D
S
D
S
