DATE+, DATE+P
Function
(1) Adds the time data designated by to the clock data designated by , and stores the result into the area starting from
the device designated by .
For example, adding the time 7:48:10 to 6:32:40 would result in the following operation:
(2) If the results of the addition of time exceed 24 hours, 24 hours will be subtracted from the sum to make the final operation
result.
For example, if the time 20:20:20 were added to 14:20:30, the result would not be 34:40:50, but would instead be
10:40:50.
Remark
See Page 573, Section 7.15.2 for further information regarding the data that can be set for hours, minutes, and seconds.
Operation Error
(1) In any of the following cases, an operation error occurs, the error flag (SM0) turns ON, and an error code is stored into
SD0.
Program Example
(1) The following program adds 1 hour to the clock data read from the clock element, and stores the results in the area
starting from D100 when X20 is ON.
[Ladder Mode]
Error
code
Error details
Q00J/
Q00/
Q01
QnH QnPH QnPRH QnU LCPU
4100
The value set for and is not within the setting range.
–– –– –– ––
4101
The range of the device specified by , or exceeds the range of
the corresponding device.
–– –– –– ––
S2
S1
D
D
S2
S1
Hour
Minute
Second
+1
+2
(0 to 23)
(0 to 59)
(0 to 59)
Hour
Minute
Second
+1
+2
(0 to 23)
(0 to 59)
(0 to 59)
Hour
Minute
Second
+1
+2
(0 to 23)
(0 to 59)
+
(0 to 59)
S1
S1
S2
S2
D
D
Data range Data range Data range
D
S2
S1
+1
+2
+1
+2
+1
+2
+
S1
S1
S2
S2
D
D
Hour: 7
Minute: 48
Second: 10
Hour: 14
Minute: 20
Second: 50
Hour: 6
Minute: 32
Second: 40
D
S2
S1
+1
+2
+1
+2
+1
+2
+
S1
S1
S2
S2
D
D
Hour: 20
Minute: 20
Second: 20
Hour: 10
Minute: 40
Second: 50
Hour: 14
Minute: 20
Second: 30
S1 S2
S1 S2
D
Reads data in the clock element to D0 or late
r
Sets the time to D0 or later
