TRACE, TRACER
Operation Error
(1) In any of the following cases, an operation error occurs, the error flag (SM0) turns on, and an error code is stored into
SD0.
Program Example
(1) The following program stores the model name of a module having the start I/O number 0020
H
in the area starting from
D0 when X0 is turned on.
[Ladder Mode] [List Mode]
Error
code
Error details
Q00J/
Q00/
Q01
QnH QnPH QnPRH QnU LCPU
2110 The target module cannot be communicated due to a failure. –– –– –– ––
4101
The range of the device specified by exceeds that of the device that
can be used.
–– –– –– ––
The value specified in n is not within the range from 0 to FF
H
or 3E0
H
to
3E3
H
.
–– –– –– –– ––
The value specified in n is not within the range from 0 to FF
H
or 3E0
H
.
–– –– –– –– ––
7.18.11 TRACE Trace set
TRACER Trace reset
7.18.11 TRACE, TRACER
• Universal model QCPU: Models other than Q00UJCPU
Setting
Data
Internal Devices
R, ZR
J\
U\G
Zn Constants Other
Bit Word Bit Word
–– ––
D
Instruction
Device
Step
Basic
Process
High
performance
Redundant Universal LCPU
Ver.
TRACE
TRACER
Command
Command
TRACE
TRACER
