(2) Transfer from file registers to file registers
*1: Unusable for the Q00UCPU and Q01UCPU.
: String to display on display unit, or lead number (string) of device storing string to display
*1: Only strings can be used
CPU Instruction
Target memory
where file register
is stored
1 word 1000 words 10000 words
Min. Max. Min. Max. Min. Max.
QnHCPU
QnPHCPU
QnPRHCPU
RBMOV
Standard RAM 20.0 µs 91.0 µs 775.0 µs
SRAM card 22.5 µs 545.0 µs 5300.0 µs
BMOV
Standard RAM 7.5 µs 77.0 µs 720.0 µs
SRAM card 8.5 µs 692.0 µs 7050.0 µs
QnCPU
RBMOV
Standard RAM 45.5 µs 215.0 µs 1850.0 µs
SRAM card 50.0 µs 870.0 µs 8350.0 µs
BMOV
Standard RAM 17.5 µs 179.0 µs 1700.0 µs
SRAM card 18.5 µs 839.0 µs 8600.0 µs
Q00UCPU
Q01UCPU
RBMOV
Standard RAM 12.6 µs 35.3 µs 232.5 µs 256.1 µs 2211.5 µs 2235.1 µs
SRAM card*1 ------
BMOV
Standard RAM 7.7 µs 14.2 µs 227.5 µs 234.2 µs 2206.5 µs 2214.2 µs
SRAM card*1 ------
Q02UCPU
RBMOV
Standard RAM 9.6 µs 31.5 µs 228.5 µs 252.3 µs 2208.5 µs 2231.3 µs
SRAM card 9.6 µs 31.5 µs 378.5 µs 401.3 µs 3708.5 µs 3731.3 µs
BMOV
Standard RAM 5.2 µs 11.8 µs 224.5 µs 232.3 µs 2204.5 µs 2212.3 µs
SRAM card 5.2 µs 11.8 µs 374.5 µs 382.3 µs 3704.5 µs 3712.3 µs
Q03UD(E)CPU
RBMOV
Standard RAM 11.2 µs 16.7 µs 230.7 µs 237.1 µs 2210.7 µs 2217.1 µs
SRAM card 11.6 µs 16.7 µs 380.7 µs 387.1 µs 3710.7 µs 3717.1 µs
BMOV
Standard RAM 4.9 µs 6.7 µs 224.7 µs 227.1 µs 2204.7 µs 2207.1 µs
SRAM card 5.2 µs 6.7 µs 374.7 µs 377.1 µs 3704.7 µs 3707.1 µs
Q04UD(E)HCPU
Q06UD(E)HCPU
Q10UD(E)HCPU
Q13UD(E)HCPU
Q20UD(E)HCPU
Q26UD(E)HCPU
Q50UDEHCPU
Q100UDEHCPU
RBMOV
Standard RAM 9.3 µs 15.5 µs 118.0 µs 124.6 µs 1102.0 µs 1107.6 µs
SRAM card 9.7 µs 15.5 µs 365.0 µs 371.6 µs 3571.0 µs 3578.6 µs
BMOV
Standard RAM 4.3 µs 6.2 µs 113.0 µs 115.6 µs 1096.0 µs 1098.6 µs
SRAM card 4.5 µs 6.1 µs 360.0 µs 362.6 µs 3566.0 µs 3568.6 µs
7.18.20 UMSG User Message
7.18.20 UMSG
Setting
Data
Internal Devices
R, ZR
Indirect
Specification
J\
U\G
Zn
Constants
Other
Bit Word Bit Word K, H
Real
String
–– ––
*1
––
Universal
Basic
High
performance
Process Redundant LCPU
UMSG
Command
UMSG
S
S
S
