Appendix 1OPERATION PROCESSING TIME Appendix 1.2Operation Processing Time of Basic Model QCPU
(2) Basic instructions
The processing time when the instruction is not executed is calculated as follows:
Q00JCPU ····················································· 0.20 (No. of steps for each instruction + 1) µs
Q00CPU ······················································· 0.16 (No. of steps for each instruction + 1) µs
Q01CPU ······················································· 0.10 (No. of steps for each instruction + 1) µs
Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
SFT
SFTP
When not executed 0.50 0.34 0.25
When executed 12 8.7 8.3
MC
M0 0.40 0.32 0.20
D0.0 3.3 2.9 2.8
MCR –– 0.20 0.16 0.10
FEND
END
Error check performed 660 600 520
No error check performed
(• Battery check)
(• Fuse blown check)
(• I/O module verification)
660 600 520
NOP –– 0.20 0.16 0.10
NOPLF
PAGE
–– 0.20 0.16 0.10
Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
LD =
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
AND =
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
OR =
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
LD < >
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
AND < >
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
OR < >
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
LD >
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
AND >
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
OR >
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
LD < =
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
AND < =
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
OR < =
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
LD <
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
