Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
AND <
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
OR <
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
LD > =
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
AND > =
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
OR > =
When not executed 0.70 0.56 0.35
When executed
In conductive status 0.80 0.64 0.40
In non-conductive status 0.80 0.64 0.40
LDD =
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
ANDD =
When not executed 0.80 0.64 0.40
When executed
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
ORD =
When not executed 0.80 0.64 0.40
When executed
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
LDD < >
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
ANDD < >
When not executed 0.80 0.64 0.40
When executed
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
ORD < >
When not executed 0.80 0.64 0.40
When executed
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
LDD >
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
ANDD >
When not executed 0.80 0.64 0.40
When executed
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
ORD >
When not executed 0.80 0.64 0.40
When executed
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
LDD < =
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
ANDD < =
When not executed 0.80 0.64 0.40
When executed
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
ORD < =
When not executed 0.80 0.64 0.40
When executed
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
LDD <
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
ANDD <
When not executed 0.80 0.64 0.40
When executed
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
ORD <
When not executed 0.80 0.64 0.40
When executed
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
LDD > =
In conductive status 1.0 0.80 0.50
In non-conductive status 1.0 0.80 0.50
