(3) Application instructions
The processing time when the instruction is not executed is calculated as follows:
Q00JCPU ·····················································0.20 (No. of steps for each instruction + 1) µs
Q00CPU ······················································· 0.16 (No. of steps for each instruction + 1) µs
Q01CPU ······················································· 0.10 (No. of steps for each instruction + 1) µs
Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
WAND
WANDP
When executed 1.0 0.80 0.50
WAND
WANDP
When executed 1.2 0.96 0.60
DAND
DANDP
When executed 1.3 1.04 0.65
DAND
DANDP
When executed 1.5 1.2 0.75
BKAND n
n = 1 110 87 79
BKANDP n
n = 96 185 155 140
WOR
WORP
When executed 1.0 0.80 0.50
WOR
WORP
When executed 1.2 0.96 0.60
DOR
DORP
When executed 1.3 1.04 0.65
DOR
DORP
When executed 1.5 1.2 0.75
BKOR n
n = 1 110 87 81
BKORP n
n = 96 185 155 140
WXOR
WXORP
When executed 1.0 0.80 0.50
WXOR
WXORP
When executed 1.2 0.96 0.60
DXOR
DXORP
When executed 1.3 1.04 0.65
DXOR
DXORP
When executed 1.5 1.2 0.75
BKXOR n
n = 1 110 87 81
BKXORP n
n = 96 185 155 140
WXNR
WXNRP
When executed 1.0 0.80 0.50
WXNR
WXNRP
When executed 1.2 0.96 0.60
DXNR
DXNRP
When executed 1.3 1.04 0.65
DXNR
DXNRP
When executed 1.5 1.2 0.75
BKXNR n
n = 1 110 87 82
BKXNRP n
n = 96 185 155 140
ROR n
n = 1 13 11 9.7
RORP n
n = 15 13 11 9.7
S
D
S
D
S1
S2
D
S1
S2
D
S
D
S
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S
D
S
D
S1
S2
D
S1
S2
D
S
D
S
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S
D
S
D
S1
S2
D
S1
S2
D
S
D
S
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S
D
S
D
S1
S2
D
S1
S2
D
S
D
S
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
D
D
