715

Appendix 1OPERATION PROCESSING TIME

Appendix 1.2Operation Processing Time of Basic Model QCPU

Instruction Condition (Device)

Processing Time (µs)

Q00JCPU Q00CPU Q01CPU

RCR n

n = 1 151212

RCRP n

n = 15 15 13 12

ROL n

n = 1 13 11 10

ROLP n

n = 15 13 11 10

RCL n

n = 1 151312

RCLP n

n = 15 16 13 12

DROR n

n = 1 151212

DRORP n

n = 31 15 13 12

DRCR n

n = 1 171414

DRCRP n

n = 31 18 16 15

DROL n

n = 1 141312

DROLP n

n = 31 14 13 12

DRCL n

n = 1 181514

DRCLP n

n = 31 20 17 16

SFR n

n = 1 13 10 9.7

SFRP n

n = 15 13 11 9.5

SFL n

n = 1 12 10 9.5

SFLP n

n = 15 12 9.8 9.5

BSFLR n

n = 1 423533

BSFLRP n

n = 96 69 58 54

BSFL n

n = 1 413432

BSFLP n

n = 96 63 53 50

DSFR n

n = 1 191615

DSFRP n

n = 96 71 61 53

DSFL n

n = 1 191615

DSFLP n

n = 96 70 60 52

BSET n

n = 1 272220

BSETP n

n = 15 27 22 20

BRST n

n = 1 272221

BRSTP n

n = 15 27 22 21

TEST

TESTP

–– 35 30 27

DTEST

DTESTP

–– 37 31 28

BKRST n

n = 1 494138

BKRSTP n

n = 96 64 54 50

SER n

SERP n

n = 1

All match 565442

None match 56 54 42

n = 96

All match 280 240 220

None match 280 240 220

DSER n

DSERP n

n = 1

All match 716753

None match 71 67 54

n = 96

All match 495 415 375

None match 500 415 375

SUM

SUMP

= 0

32 26 25

= FFFF

27 22 21
