Mitsubishi MELSEC-Q/L User Manual

716
Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
DSUM
DSUMP
= 0
54 44 42
= FFFFFFFF
H
54 44 42
DECO n
n = 2 60 50 46
DECOP n
n = 8 80 65 61
ENCO n
ENCOP n
n = 2
M1 = ON 66 55 51
M4 = ON 66 54 51
n = 8
M1 = ON 90 76 71
M256 = ON 76 74 71
SEG
SEGP
–– 8.0 6.8 6.1
DIS n
n = 1 47 39 36
DISP n
n = 4 53 43 40
UNI n
n = 1 54 44 41
UNIP n
n = 4 60 49 46
NDIS
NDISP
–– 92 76 38
NUNI
NUNIP
–– 47 39 36
WTOB n
n = 1 56 46 42
WTOBP n
n = 96 190 155 145
BTOW n
n = 1 56 46 42
BTOWP n
n = 96 190 155 145
MAX n
n = 1 48 40 36
MAXP n
n = 96 300 240 235
MIN n
n = 1 48 40 36
MINP n
n = 96 300 240 235
DMAX n
n = 1 52 43 39
DMAXP n
n = 96 600 490 460
DMIN n
n = 1 52 43 39
DMINP n
n = 96 585 475 445
SORT n
n = 1, = 1
66 55 50
n = 96, = 16
329 270 252
DSORT n
n = 1, = 1
98 57 52
n = 96, = 16
386 317 294
WSUM n
n = 1 52 43 40
WSUMP n
n = 96 175 140 135
DWSUM n
n = 1 61 51 46
DWSUMP n
n = 96 515 420 395
FOR n n = 0 11 8.9 8.1
NEXT –– 8.8 7.3 6.8
BREAK
BREAKP
–– 37 30 28
CALL Pn
CALLP Pn
–– 17 14 13
CALL Pn to
CALLP Pn to
–– 245 200 190
RET Return to original program 16 13 12
S
S
S
D
S
D
S
D
S
D
S
D
S
D
S
D
S
D
S1
D
S2
S1
D
S2
S1
D
S2
S1
D
S2
S
D
S
D
S
D
S
D
S
D
S
D
S
D
S
D
S
D
S
D
S
D
S
D
S1
S2
D1 D2
S2
S2
S1
S2
D1 D2
S2
S2
S
D
S
D
S
D
S
D
S1
S5
S1
S5
