(4) Processing time for QCPU instructions (QCPU instructions only)
(5)
Instructions executable by the product with the first 5 digits of the serial No. "04122" or higher
Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
HOUR
HOURP
–– 38 32 29
WDT
WDTP
–– 18 15 14
DUTY –– 41 36 32
ZRRDB
ZRRDBP
–– –– 24 22
ZRWRB
ZRWRBP
–– –– 27 24
ADRSET
ADRSETP
–– 23 19 18
ZPUSH
ZPUSHP
–– 38 33 30
ZPOP
ZPOPP
–– 37 31 29
ZCOM –– 105 82 80
Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
UNIRD
UNIRDP
n = 1 96 80 74
n = 16 440 370 340
Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
LDE = Single precision
In conductive status 43.0 35.5 33.0
In non-conductive status 46.0 38.0 35.5
ANDE = Single precision
When not executed 1.5 1.2 1.0
When
executed
In conductive status 35.5 29.5 26.5
In non-conductive status 42.0 35.0 32.5
ORE = Single precision
When not executed 1.5 1.2 1.0
When
executed
In conductive status 42.0 35.0 32.5
In non-conductive status 37.0 31.0 28.5
LDE < > Single precision
In conductive status 46.0 38.0 35.5
In non-conductive status 43.5 36.0 33.0
ANDE < > Single precision
When not executed 1.5 1.2 1.0
When
executed
In conductive status 38.5 31.5 29.0
In non-conductive status 39.5 33.0 30.5
ORE < > Single precision
When not executed 1.5 1.2 1.0
When
executed
In conductive status 45.0 37.5 35.0
In non-conductive status 34.5 29.0 26.5
LDE > Single precision
In conductive status 46.0 37.5 35.5
In non-conductive status 46.0 38.5 35.0
ANDE > Single precision
When not executed 1.5 1.2 1.0
When
executed
In conductive status 38.5 32.0 29.0
In non-conductive status 42.0 35.0 32.5
ORE > Single precision
When not executed 1.5 1.2 1.0
When
executed
In conductive status 45.0 37.5 34.5
In non-conductive status 37.0 31.0 29.0
LDE < = Single precision
In conductive status 45.5 37.5 35.0
In non-conductive status 46.5 38.5 35.5
ANDE < = Single precision
When not executed 1.5 1.2 1.0
When
executed
In conductive status 38.5 31.5 29.0
In non-conductive status 42.5 35.5 32.5
