Appendix 1OPERATION PROCESSING TIME Appendix 1.3Operation Processing Time of High Performance Model QCPU/Process CPU/Redundant
CPU
Instruction Condition (Device)
Processing Time (µs)
Qn QnH QnPH QnPRH
OUTH T
When not executed 0.63 0.27 0.27 0.27
When
executed
After time up 0.63 0.27 0.27 0.27
When added
K 0.63 0.27 0.27 0.27
D 0.63 0.27 0.27 0.27
SET
When not executed 0.158 0.068 0.068 0.068
When executed
When not changed (ON ON)
0.158 0.068 0.068 0.068
When changed (OFF ON)
0.158 0.068 0.068 0.068
F
When not executed 0.47 0.20 0.20 0.20
When
executed
When displayed 161 69 69 69
Display completed 0.47 0.20 0.20 0.20
RST
When not executed 0.158 0.068 0.068 0.068
When executed
When not changed
(OFF OFF)
0.158 0.068 0.068 0.068
When changed (ON OFF)
0.158 0.068 0.068 0.068
SM
When not executed 0.158 0.068 0.068 0.068
When executed 0.158 0.068 0.068 0.068
F
When not executed 0.47 0.20 0.20 0.20
When
executed
When displayed 90 38 38 38
Display completed 0.47 0.20 0.20 0.20
T, C
When not executed 0.63 0.27 0.27 0.27
When executed 0.63 0.27 0.27 0.27
D
When not executed 0.24 0.10 0.10 0.10
When executed 0.24 0.10 0.10 0.10
Z
When not executed 0.47 0.20 0.20 0.20
When executed 4.3 1.9 1.9 1.9
R
When not executed 0.40 0.17 0.17 0.17
When executed 0.40 0.17 0.17 0.17
PLS
PLF
–– 1.0 0.44 0.44 0.44
FF Y
When not executed 0.47 0.20 0.20 0.20
When executed 0.47 0.20 0.20 0.20
DELTA
DELTAP
DY0
When not executed 0.47 0.20 0.20 0.20
When executed 5.9 2.6 2.6 2.6
SFT
SFTP
When not executed 0.47 0.20 0.20 0.20
When executed 1.66 0.71 0.71 0.71
MC –– 0.24 0.10 0.10 0.10
MCR –– 0.079 0.034 0.034 0.034
FEND
END
Error check performed 380 150 150 500
No error check performed
(• Battery check)
(• Fuse blown check)
(• I/O module verification)
380 150 150 500
NOP –– 0.079 0.034 0.034 0.034
NOPLF
PAGE
–– 0.079 0.034 0.034 0.034
