Appendix 1OPERATION PROCESSING TIME Appendix 1.4Operation Processing Time of Universal Model QCPU
Appendix 1.4.2 Processing time of instructions other than subset instruction
The following table shows the processing time of instructions other than subset instructions.
• The processing time shown in "(1) Table of the processing time of instructions other than subset instructions" applies
when the device used in an instruction does not meet the device condition for subset processing (For device condition
that does not trigger subset processing, refer to Page 102, Section 3.5.1).
For instructions not shown in the following table, refer to "(1) Subset instruction processing time table" in Page 746,
Appendix 1.4.1(1).
• When using a file resister (R, ZR), extended data register (D), extended link register (W), module access device (Un\G
and U3En\G0 to G4095), and link direct device (Jn\ ), add the processing time shown in (2) to that of the instruction.
• Since the processing time of an instruction varies depending on that of the cash function, both the minimum and
maximum values are described in the table.
(1) Table of the processing time of instructions other than subset instructions
(a) When using Q00UJCPU, Q00UCPU, Q01UCPU and Q02UCPU
Category Instruction Condition (Device)
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU Q02UCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Sequence
instruction
ANB
ORB
MPS
MRD
MPP
––
0.120 0.080 0.060 0.040
INV
When not executed
0.120 0.080 0.060 0.040
When executed
MEP
MEF
When not executed
0.120 0.080 0.060 0.040
When executed
EGP
EGF
When not executed
0.120 0.080 0.060 0.040
When executed
PLS ––
1.800 1.900 1.800 1.900 1.800 1.900 1.300 1.600
PLF ––
1.800 1.900 1.800 1.900 1.800 1.900 1.600 1.700
FF
When not executed
0.240 0.160 0.120 0.080
When executed
1.700 1.800 1.700 1.800 1.700 1.800 1.200 1.500
DELTA
When not executed
0.240 0.160 0.120 0.080
When executed
4.000 14.700 4.000 14.700 4.000 14.700 2.800 3.600
SFT
When not executed
0.240 0.160 0.120 0.800
When executed
1.800 12.600 1.800 12.600 1.800 12.600 1.600 6.600
MC ––
0.240 0.160 0.120 0.080
MCR ––
0.120 0.080 0.060 0.040
FEND
END
Error check performed
250.000 250.000 250.000 250.000 250.000 250.000 175.000 252.000
No error check performed
250.000 250.000 250.000 250.000 250.000 250.000 175.000 221.000
NOP
NOPLF
PAGE
––
0.120 0.080 0.060 0.040
