Mitsubishi MELSEC-Q/L

760
Category Instruction Condition (Device)
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU Q02UCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Basic
instruction
LDE=
Single
precision
In conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 10.100
In non-conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 10.100
ANDE=
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.200 12.500
In non-conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.400 11.900
ORE=
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.600 10.800
In non-conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.500 9.800
LDE< >
Single
precision
In conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 7.700
In non-conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.600 8.200
ANDE< >
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.300 14.200
In non-conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.400 14.200
ORE< >
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.600 6.700
In non-conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.400 6.600
LDE>
Single
precision
In conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 13.700
In non-conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.600 13.700
ANDE>
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.300 8.100
In non-conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.200 8.100
ORE>
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.600 8.500
In non-conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.400 8.100
LDE<=
Single
precision
In conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 11.100
In non-conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 9.600
ANDE<=
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.100 7.800
In non-conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.400 8.200
ORE<=
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.500 10.300
In non-conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.400 9.800
LDE<
Single
precision
In conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 11.500
In non-conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 10.900
ANDE<
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.300 9.200
In non-conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.400 9.400
ORE<
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.600 10.400
In non-conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.400 9.800
LDE>=
Single
precision
In conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 12.200
In non-conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 11.800
ANDE>=
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.100 6.700
In non-conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.400 7.000
ORE>=
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.600 14.000
In non-conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.500 14.300
LDED=
Double
precision
In conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 21.000
In non-conductive status
4.700 37.400 4.700 37.400 4.700 37.400 5.100 21.900
ANDED=
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.500 34.700 4.500 34.700 4.500 34.700 3.800 17.800
In non-conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.100 18.100
