Appendix 1OPERATION PROCESSING TIME Appendix 1.4Operation Processing Time of Universal Model QCPU
Category Instruction Condition (Device)
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU Q02UCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Basic
instruction
ORED=
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.700 33.200 4.700 33.200 4.700 33.200 4.100 23.800
In non-conductive status
4.700 33.200 4.700 33.200 4.700 33.200 4.900 25.500
LDED<>
Double
precision
In conductive status
4.700 37.400 4.700 37.400 4.700 37.400 5.100 23.500
In non-conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 22.600
ANDED<>
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.000 18.800
In non-conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.000 18.700
ORED<>
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 25.200
In non-conductive status
4.700 33.200 4.700 33.200 4.700 33.200 4.100 23.400
LDED>
Double
precision
In conductive status
4.700 37.400 4.700 37.400 4.700 37.400 5.100 25.100
In non-conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 23.400
ANDED>
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.000 19.500
In non-conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.100 19.700
ORED>
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 24.200
In non-conductive status
4.700 33.200 4.700 33.200 4.700 33.200 4.900 25.800
LDED<=
Double
precision
In conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 22.500
In non-conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 13.500
ANDED<=
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.000 19.600
In non-conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.100 19.700
ORED<=
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 26.300
In non-conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 25.200
LDED<
Double
precision
In conductive status
4.700 37.400 4.700 37.400 4.700 37.400 5.100 25.000
In non-conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 24.100
ANDED<
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.000 19.400
In non-conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.100 19.700
ORED<
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 25.100
In non-conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 25.100
LDED>=
Double
precision
In conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 13.100
In non-conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.300 13.100
ANDED>=
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.500 34.700 4.500 34.700 4.500 34.700 3.900 19.500
In non-conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.100 19.800
ORED>=
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 25.100
In non-conductive status
4.700 33.200 4.700 33.200 4.700 33.200 4.200 18.500
LD$=
In conductive status
8.300 38.500 8.300 38.500 8.300 38.500 5.500 14.900
In non-conductive status
8.300 38.500 8.300 38.500 8.300 38.500 5.500 15.600
AND$=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
7.200 37.300 7.200 37.300 7.200 37.300 5.200 13.800
In non-conductive status
7.200 37.300 7.200 37.300 7.200 37.300 5.300 14.500
OR$=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
7.500 36.600 7.500 36.600 7.500 36.600 5.500 14.900
In non-conductive status
7.500 36.600 7.500 36.600 7.500 36.600 5.300 14.600
