Mitsubishi MELSEC-Q/L

762
Category Instruction Condition (Device)
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU Q02UCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Basic
instruction
LD$< >
In conductive status
8.300 39.300 8.300 39.300 8.300 39.300 5.600 15.200
In non-conductive status
8.300 39.300 8.300 39.300 8.300 39.300 5.600 15.400
AND$< >
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
8.000 38.200 8.000 38.200 8.000 38.200 4.300 21.500
In non-conductive status
8.000 38.200 8.000 38.200 8.000 38.200 4.500 23.400
OR$< >
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
8.300 37.300 8.300 37.300 8.300 37.300 5.400 17.700
In non-conductive status
8.300 37.300 8.300 37.300 8.300 37.300 5.300 19.400
LD$>
In conductive status
8.300 41.600 8.300 41.600 8.300 41.600 6.400 19.200
In non-conductive status
8.300 41.600 8.300 41.600 8.300 41.600 5.600 20.100
AND$>
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
8.000 38.100 8.000 38.100 8.000 38.100 4.500 15.400
In non-conductive status
8.000 38.100 8.000 38.100 8.000 38.100 4.600 15.300
OR$>
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
8.200 35.700 8.200 35.700 8.200 35.700 5.400 20.000
In non-conductive status
8.200 35.700 8.200 35.700 8.200 35.700 5.400 22.100
LD$<=
In conductive status
8.300 39.200 8.300 39.200 8.300 39.200 5.800 12.800
In non-conductive status
8.300 39.200 8.300 39.200 8.300 39.200 6.300 13.900
AND$<=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
7.100 36.500 7.100 36.500 7.100 36.500 6.000 16.000
In non-conductive status
7.100 36.500 7.100 36.500 7.100 36.500 6.100 16.200
OR$<=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
7.400 35.600 7.400 35.600 7.400 35.600 4.700 14.600
In non-conductive status
7.400 35.600 7.400 35.600 7.400 35.600 4.600 14.400
LD$<
In conductive status
7.400 40.000 7.400 40.000 7.400 40.000 4.800 17.000
In non-conductive status
7.400 40.000 7.400 40.000 7.400 40.000 5.500 18.000
AND$<
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
8.000 37.300 8.000 37.300 8.000 37.300 5.900 13.400
In non-conductive status
8.000 37.300 8.000 37.300 8.000 37.300 6.200 14.500
OR$<
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
8.300 35.600 8.300 35.600 8.300 35.600 6.200 18.700
In non-conductive status
8.300 35.600 8.300 35.600 8.300 35.600 5.400 19.700
LD$>=
In conductive status
7.400 38.300 7.400 38.300 7.400 38.300 4.800 10.000
In non-conductive status
7.400 38.300 7.400 38.300 7.400 38.300 5.500 11.200
AND$>=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
7.200 37.300 7.200 37.300 7.200 37.300 4.400 21.600
In non-conductive status
7.200 37.300 7.200 37.300 7.200 37.300 4.500 21.800
OR$>=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
8.200 36.400 8.200 36.400 8.200 36.400 5.400 15.400
In non-conductive status
8.200 36.400 8.200 36.400 8.200 36.400 5.300 15.300
