Mitsubishi MELSEC-Q/L

776
Category Instruction Condition (Device)
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU Q02UCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Application
instruction
ANDTM<=
When not executed
0.480 0.320 0.240 0.160
Comparison
of specified
clock
In conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.000 23.000
In non-conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.000 23.000
Comparison
of current
clock
In conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.600 21.900
In non-conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.600 21.900
ORTM<=
When not executed
0.480 0.320 0.240 0.160
Comparison
of specified
clock
In conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.300 23.200
In non-conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.300 23.200
Comparison
of current
clock
In conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.900 22.000
In non-conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.900 22.000
LDTM<
Comparison
of specified
clock
In conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.300 23.300
In non-conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.300 23.300
Comparison
of current
clock
In conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.900 22.100
In non-conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.900 22.100
ANDTM<
When not executed
0.480 0.320 0.240 0.160
Comparison
of specified
clock
In conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.000 23.000
In non-conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.000 23.000
Comparison
of current
clock
In conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.600 21.900
In non-conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.600 21.900
ORTM<
When not executed
0.480 0.320 0.240 0.160
Comparison
of specified
clock
In conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.300 23.200
In non-conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.300 23.200
Comparison
of current
clock
In conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.900 22.000
In non-conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.900 22.000
LDTM>=
Comparison
of specified
clock
In conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.300 23.300
In non-conductive
status
8.200 25.500 8.200 25.500 6.500 25.500 7.300 23.300
Comparison
of current
clock
In conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.900 22.100
In non-conductive
status
6.500 23.100 6.500 23.100 6.500 23.100 5.900 22.100
