Mitsubishi MELSEC-Q/L

778
Category Instruction Condition (Device)
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU Q02UCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Application
instruction
S.ZCOM
When mounting CC-Link
module (master station side)
29.400 91.700 29.400 91.700 29.400 91.700 20.600 55.000
When mounting CC-Link
module (local station side)
29.500 91.600 29.500 91.600 29.500 91.600 20.600 66.100
• When selecting
MELSECNET/H refresh only
(control station side)
• When selecting CC-Link IE
Controller Network refresh
only (control station side)
79.900 214.000 79.900 214.000 79.900 214.000 102.000 180.000
• When selecting
MELSECNET/H refresh only
(normal station side)
• When selecting CC-Link IE
Controller Network refresh
only (normal station side)
79.900 214.000 79.900 214.000 79.900 214.000 55.600 168.100
When selecting CC-Link IE Field
Network refresh only (master
station side)
60.000 167.000 60.000 167.000 60.000 167.000 51.000 154.000
When selecting CC-Link IE Field
Network refresh only (local
station side)
60.000 167.000 60.000 167.000 60.000 167.000 51.000 154.000
S.RTREAD ––
12.600 65.000 12.600 65.000 12.600 65.000 8.700 60.500
S.RTWRIT
E
––
13.300 67.100 13.300 67.100 13.300 67.100 9.300 65.000
UNIRD n1
n2
n2 = 1
6.000 33.100 6.000 33.100 6.000 33.100 4.000 29.100
n2 = 16
16.500 43.600 16.500 43.600 16.500 43.600 12.500 37.600
TYPERD ––
48.50 141.30 43.50 139.90 43.40 139.80 32.40 134.20
TRACE Start
174.000 174.000 174.000 174.000 174.000 174.000 96.600 103.000
TRACER ––
5.100 15.500 5.100 15.500 5.100 15.500 3.800 13.600
RBNOV
n
When
standard
RAM is
used
1 point
–– –– 12.200 34.900 12.200 34.900 9.400 31.300
1000 points
–– –– 121.500 145.100 121.500 145.100 118.500 141.300
When
SRAM
card is used
1 point
–– –– –– –– –– –– 9.400 31.400
1000 points
–– –– –– –– –– –– 178.500 201.300
SP.FWRIT
E
––
–– –– –– –– –– –– 9.200 12.100
SP.FREAD ––
–– –– –– –– –– –– 489.000 544.000
SP.DEVST ––
–– –– –– –– –– –– 87.000 144.000
S.DEVLD ––
–– –– –– –– –– –– 127.000 140.000
