Category Instruction Condition (Device)
Processing Time (µs)
Q03
UD(E)CPU
Q04/Q06
UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Q50/Q100
UDEHCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Application
instruction
ANDTM<>
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
clock
In conductive status
7.000 11.500 6.300 10.800 6.300 10.800 6.300 10.800
In non-conductive status
7.000 11.500 6.300 10.800 6.300 10.800 6.300 10.800
Comparison
of current
clock
In conductive status
5.500 9.900 5.100 9.500 5.100 9.500 5.100 9.500
In non-conductive status
5.500 9.900 5.100 9.500 5.100 9.500 5.100 9.500
ORTM<>
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
clock
In conductive status
7.300 11.500 6.600 10.800 6.600 10.800 6.600 10.800
In non-conductive status
7.300 11.500 6.600 10.800 6.600 10.800 6.600 10.800
Comparison
of current
clock
In conductive status
5.900 9.900 5.300 9.500 5.300 9.500 5.300 9.500
In non-conductive status
5.900 9.900 5.300 9.500 5.300 9.500 5.300 9.500
LDTM>
Comparison
of specified
clock
In conductive status
7.300 11.500 6.700 10.800 6.700 10.800 6.700 10.800
In non-conductive status
7.300 11.500 6.700 10.800 6.700 10.800 6.700 10.800
Comparison
of current
clock
In conductive status
5.800 9.900 5.400 9.500 5.400 9.500 5.400 9.500
In non-conductive status
5.800 9.900 5.400 9.500 5.400 9.500 5.400 9.500
ANDTM>
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
clock
In conductive status
7.000 11.500 6.300 10.800 6.300 10.800 6.300 10.800
In non-conductive status
7.000 11.500 6.300 10.800 6.300 10.800 6.300 10.800
Comparison
of current
clock
In conductive status
5.500 9.900 5.100 9.500 5.100 9.500 5.100 9.500
In non-conductive status
5.500 9.900 5.100 9.500 5.100 9.500 5.100 9.500
ORTM>
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
clock
In conductive status
7.300 11.500 6.600 10.800 6.600 10.800 6.600 10.800
In non-conductive status
7.300 11.500 6.600 10.800 6.600 10.800 6.600 10.800
Comparison
of current
clock
In conductive status
5.900 9.900 5.300 9.500 5.300 9.500 5.300 9.500
In non-conductive status
5.900 9.900 5.300 9.500 5.300 9.500 5.300 9.500
LDTM<=
Comparison
of specified
clock
In conductive status
7.300 11.500 6.700 10.800 6.700 10.800 6.700 10.800
In non-conductive status
7.300 11.500 6.700 10.800 6.700 10.800 6.700 10.800
Comparison
of current
clock
In conductive status
5.800 9.900 5.400 9.500 5.400 9.500 5.400 9.500
In non-conductive status
5.800 9.900 5.400 9.500 5.400 9.500 5.400 9.500
ANDTM<=
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
clock
In conductive status
7.000 11.500 6.300 10.800 6.300 10.800 6.300 10.800
In non-conductive status
7.000 11.500 6.300 10.800 6.300 10.800 6.300 10.800
Comparison
of current
clock
In conductive status
5.500 9.900 5.100 9.500 5.100 9.500 5.100 9.500
In non-conductive status
5.500 9.900 5.100 9.500 5.100 9.500 5.100 9.500
