Appendix 1OPERATION PROCESSING TIME Appendix 1.4Operation Processing Time of Universal Model QCPU
Category Instruction Condition (Device)
Processing Time (µs)
Q03
UD(E)CPU
Q04/Q06
UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Q50/Q100
UDEHCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Application
instruction
ORTM<=
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
clock
In conductive status
7.300 11.500 6.600 10.800 6.600 10.800 6.600 10.800
In non-conductive status
7.300 11.500 6.600 10.800 6.600 10.800 6.600 10.800
Comparison
of current
clock
In conductive status
5.900 9.900 5.300 9.500 5.300 9.500 5.300 9.500
In non-conductive status
5.900 9.900 5.300 9.500 5.300 9.500 5.300 9.500
LDTM<
Comparison
of specified
clock
In conductive status
7.300 11.500 6.700 10.800 6.700 10.800 6.700 10.800
In non-conductive status
7.300 11.500 6.700 10.800 6.700 10.800 6.700 10.800
Comparison
of current
clock
In conductive status
5.800 9.900 5.400 9.500 5.400 9.500 5.400 9.500
In non-conductive status
5.800 9.900 5.400 9.500 5.400 9.500 5.400 9.500
ANDTM<
When not executed
0.480 0.320 0.240 0.240
Comparison
of specified
clock
In conductive status
8.200 25.500 8.200 25.500 6.500 25.500 6.500 25.500
In non-conductive status
8.200 25.500 8.200 25.500 6.500 25.500 6.500 25.500
Comparison
of current
clock
In conductive status
6.500 23.100 6.500 23.100 6.500 23.100 6.500 23.100
In non-conductive status
6.500 23.100 6.500 23.100 6.500 23.100 6.500 23.100
ORTM<
When not executed
0.480 0.320 0.240 0.240
Comparison
of specified
clock
In conductive status
8.200 25.500 8.200 25.500 6.500 25.500 6.500 25.500
In non-conductive status
8.200 25.500 8.200 25.500 6.500 25.500 6.500 25.500
Comparison
of current
clock
In conductive status
6.500 23.100 6.500 23.100 6.500 23.100 6.500 23.100
In non-conductive status
6.500 23.100 6.500 23.100 6.500 23.100 6.500 23.100
LDTM<
Comparison
of specified
clock
In conductive status
7.300 11.500 6.700 10.800 6.700 10.800 6.700 10.800
In non-conductive status
7.300 11.500 6.700 10.800 6.700 10.800 6.700 10.800
Comparison
of current
clock
In conductive status
5.800 9.900 5.400 9.500 5.400 9.500 5.400 9.500
In non-conductive status
5.800 9.900 5.400 9.500 5.400 9.500 5.400 9.500
ANDTM<
When not executed
0.480 0.320 0.240 0.240
Comparison
of specified
clock
In conductive status
8.200 25.500 8.200 25.500 6.500 25.500 6.500 25.500
In non-conductive status
8.200 25.500 8.200 25.500 6.500 25.500 6.500 25.500
Comparison
of current
clock
In conductive status
6.500 23.100 6.500 23.100 6.500 23.100 6.500 23.100
In non-conductive status
6.500 23.100 6.500 23.100 6.500 23.100 6.500 23.100
ORTM<
When not executed
0.480 0.320 0.240 0.240
Comparison
of specified
clock
In conductive status
8.200 25.500 8.200 25.500 6.500 25.500 6.500 25.500
In non-conductive status
8.200 25.500 8.200 25.500 6.500 25.500 6.500 25.500
Comparison
of current
clock
In conductive status
6.500 23.100 6.500 23.100 6.500 23.100 6.500 23.100
In non-conductive status
6.500 23.100 6.500 23.100 6.500 23.100 6.500 23.100
S.DATERD ––
9.250 51.000 9.250 51.000 9.250 51.000 9.250 51.000
S.DATE +
No digit increase
16.800 75.400 16.800 75.400 16.800 75.400 16.800 75.400
Digit increase
16.800 75.400 16.800 75.400 16.800 75.400 16.800 75.400
S.DATE -
No digit increase
17.600 75.300 17.600 75.300 17.600 75.300 17.600 75.300
Digit increase
16.900 75.300 16.900 75.300 16.900 75.300 16.900 75.300
