Category Instruction Condition (Device)
Processing Time (µs)
L02CPU, L02CPU-P L26CPU-BT, L26CPU-PBT
Min. Max. Min. Max.
Basic
instruction
ANDD<>
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
ORD<>
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
LDD>
In conductive status
0.120 0.0285
In non-conductive status
ANDD>
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
ORD>
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
LDD<=
In conductive status
0.120 0.0285
In non-conductive status
ANDD<=
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
ORD<=
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
LDD<
In conductive status
0.120 0.0285
In non-conductive status
ANDD<
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
ORD<
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
LDD>=
In conductive status
0.120 0.0285
In non-conductive status
ANDD>=
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
ORD>=
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
+
When executed
0.120 0.0285
+
When executed
0.160 0.038
-
When executed
0.120 0.0285
-
When executed
0.160 0.038
D +
When executed
0.120 0.0285
D +
When executed
0.160 0.038
D -
When executed
0.120 0.0285
D -
When executed
0.160 0.038
*
When executed
0.180 0.057
/
When executed
0.280 0.105
D *
When executed
0.260 0.095
D/
When executed
0.400 0.162
B +
When executed
3.100 6.800 2.900 4.100
B +
When executed
4.800 8.900 4.200 5.900
S
D
S1
S2
D
S
D
S1
S2
D
S
D
S1
S2
D
S
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S
D
S1
S2
D
