Appendix 1OPERATION PROCESSING TIME Appendix 1.5Operation Processing Time of LCPU
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU, L02CPU-P L26CPU-BT, L26CPU-PBT
Min. Max. Min. Max.
Basic
instruction
B -
When executed
3.100 6.800 2.900 4.100
B -
When executed
4.800 8.900 4.200 4.600
B *
When executed
3.900 7.400 3.400 4.800
B/
When executed
3.900 8.500 3.700 5.200
E +
Single precision
= 0, = 0
0.180 0.057
= 2
127
, = 2
127
0.180 0.057
E +
Single precision
= 0, = 0
0.220 0.0665
= 2
127
, = 2
127
0.220 0.0665
E -
Single precision
= 0, = 0
0.180 0.057
= 2
127
, = 2
127
0.180 0.057
E -
Single precision
= 0, = 0
0.220 0.0665
= 2
127
, = 2
127
0.220 0.0665
E *
Single precision
= 0, = 0
0.180 0.057
= 2
127
, = 2
127
0.180 0.057
E/
Single precision
= 2
127
, = 2
127
3.900 8.500 0.285
INC When executed
0.080 0.019
DINC When executed
0.080 0.019
DEC When executed
0.080 0.019
DDEC When executed
0.080 0.019
BCD When executed
0.160 0.057
DBCD When executed
0.240 0.095
BIN When executed
0.100 0.0285
DBIN When executed
0.100 0.0285
FLT Single precision
= 0
0.100 0.0475
= 7FFF
H
0.140 0.0475
DFLT Single precision
= 0
0.140 0.0475
= 7FFFFFFF
H
0.140 0.0475
INT Single precision
= 0
0.140 0.0475
= 32766.5
0.140 0.0475
DINT Single precision
= 0
0.140 0.0475
= 1234567890.3
0.140 0.0475
MOV ––
0.080 0.019
DMOV ––
0.080 0.019
EMOV ––
0.080 0.019
CML ––
0.080 0.019
DCML ––
0.080 0.019
BMOV
SM237=ON
n=1
3.600 4.100 2.900 3.200
n=96
4.500 4.700 3.400 3.700
SM237=OFF
n=1
5.000 7.400 4.200 5.500
n=96
6.000 7.900 4.700 6.000
FMOV
SM237=ON
n=1
5.900 6.800 2.800 3.200
n=96
6.300 11.000 3.000 5.200
SM237=OFF
n=1
7.000 8.000 3.400 3.800
n=96
5.200 6.900 3.600 5.800
XCH ––
2.100 4.100 1.800 2.300
DXCH ––
2.200 4.200 2.100 2.900
