Mitsubishi MELSEC-Q/L

806
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU, L02CPU-P L26CPU-BT, L26CPU-PBT
Min. Max. Min. Max.
Basic
instruction
DFMOV
SM237=ON
n=1
2.000 3.200 1.750 1.750
n=96
5.600 6.100 3.650 4.150
SM237=OFF
n=1
2.900 4.600 2.250 3.150
n=96
6.100 8.200 4.200 5.500
CJ ––
2.100 2.900 1.100 2.400
SCJ ––
2.100 2.900 1.100 2.400
JMP ––
2.100 2.900 1.100 2.400
Application
instruction
WAND
When executed
0.120 0.0285
WAND
When executed
0.160 0.038
DAND
When executed
0.120 0.0285
DAND
When executed
0.160 0.038
WOR
When executed
0.120 0.0285
WOR
When executed
0.160 0.038
DOR
When executed
0.120 0.0285
DOR
When executed
0.160 0.038
WXOR
When executed
0.120 0.0285
WXOR
When executed
0.160 0.038
DXOR
When executed
0.120 0.0285
DXOR
When executed
0.160 0.038
WXNR
When executed
0.120 0.0285
WXNR
When executed
0.160 0.038
DXNR
When executed
0.120 0.0285
DXNR
When executed
0.160 0.038
ROR n
n = 1
2.200 4.900 1.700 2.500
n = 15
2.200 4.900 1.700 2.500
RCR n
n = 1
2.100 4.800 1.700 3.200
n = 15
2.100 4.800 1.700 3.200
ROL n
n = 1
2.100 4.800 1.800 3.200
n = 15
2.100 4.800 1.800 3.200
RCL n
n = 1
2.100 5.200 1.800 2.200
n = 15
2.100 5.200 1.800 2.200
DROR n
n = 1
2.200 5.200 1.900 2.700
n = 31
2.200 5.200 1.900 2.700
DRCR n
n = 1
2.200 5.900 1.900 4.200
n = 31
2.200 5.900 1.900 4.200
DROL n
n = 1
2.200 4.900 1.800 3.300
n = 31
2.200 4.900 1.800 3.300
DRCL n
n = 1
2.200 5.900 1.900 3.800
n = 31
2.200 5.900 1.900 3.800
SFR n
n = 1
2.200 4.600 1.700 2.600
n = 15
2.200 4.600 1.700 2.600
SFL n
n = 1
2.200 4.600 1.800 2.700
n = 15
2.200 4.600 1.800 2.700
DSFR n
n = 1
2.200 6.100 2.200 4.300
n = 96
33.400 38.100 23.900 26.100
DSFL n
n = 1
2.200 6.100 2.100 4.000
n = 96
33.500 38.000 23.700 25.800
SUM
= 0
3.000 4.800 2.900 3.600
= FFFF
H
3.000 4.900 2.900 3.600
SEG When executed
1.700 3.600 1.500 2.100
S
D
S1
S2
D
S
D
S1
S2
D
S
D
S1
S2
D
S
D
S1
S2
D
S
D
S1
S2
D
S
D
S1
S2
D
S
D
S1
S2
D
S
D
S1
S2
D
D
D
D
D
D
D
D
D
D
D
D
D
S
S
