Appendix 1OPERATION PROCESSING TIME Appendix 1.5Operation Processing Time of LCPU
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU, L02CPU-P L26CPU-BT, L26CPU-PBT
Min. Max. Min. Max.
Application
instruction
LDTM>=
Comparison
of specified
clock
In conductive status
7.600 14.000 6.700 10.800
In non-conductive
status
7.600 14.000 6.700 10.800
Comparison
of current
clock
In conductive status
6.200 12.700 5.400 9.500
In non-conductive
status
6.200 12.700 5.400 9.500
ANDTM>=
When not executed
0.160 0.038
Comparison
of specified
clock
In conductive status
7.200 13.900 6.300 10.800
In non-conductive
status
7.200 13.900 6.300 10.800
Comparison
of current
clock
In conductive status
5.900 12.500 5.100 9.500
In non-conductive
status
5.900 12.500 5.100 9.500
ORTM>=
When not executed
0.160 0.038
Comparison
of specified
clock
In conductive status
7.300 14.100 6.600 10.800
In non-conductive
status
7.300 14.100 6.600 10.800
Comparison
of current
clock
In conductive status
6.000 12.700 5.300 9.500
In non-conductive
status
6.000 12.700 5.300 9.500
SCL
SM750
= ON
Point No.1 < <
Point No.2
12.500 29.200 11.900 23.000
Point No.9 < <
Point No.10
13.200 29.100 12.100 23.000
SM750
= OFF
Point No.1 < <
Point No.2
12.100 28.900 10.900 22.200
Point No.9 < <
Point No.10
13.900 30.900 12.700 23.900
DSCL
SM750
= ON
Point No.1 < <
Point No.2
12.500 29.200 11.900 23.000
Point No.9 < <
Point No.10
13.200 29.100 12.100 23.000
SM750
= OFF
Point No.1 < <
Point No.2
12.100 28.900 10.900 22.200
Point No.9 < <
Point No.10
13.900 30.900 12.700 23.900
SCL2
SM750
= ON
Point No.1 < <
Point No.2
13.400 29.700 11.800 23.300
Point No.9 < <
Point No.10
12.900 29.500 12.100 23.300
SM750
= OFF
Point No.1 < <
Point No.2
12.200 29.100 11.000 22.600
Point No.9 < <
Point No.10
13.900 30.700 12.600 23.900
DSCL2
SM750
= ON
Point No.1 < <
Point No.2
13.400 29.700 11.800 23.300
Point No.9 < <
Point No.10
12.900 29.500 12.100 23.300
SM750
= OFF
Point No.1 < <
Point No.2
12.200 29.100 11.000 22.600
Point No.9 < <
Point No.10
13.900 30.700 12.600 23.900
