Mitsubishi MELSEC-Q/L

824
Remark
For the instructions for which a rise execution instruction ( P) is not specified, the processing time is the same as an ON
execution instruction.
WORDP instruction and TOP instruction
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU, L02CPU-P L26CPU-BT, L26CPU-PBT
Min. Max. Min. Max.
Application
instruction
RSET Standard RAM
3.500 11.100 2.700 5.900
DATE -
No digit increase
9.000 17.900 4.600 7.000
Digit increase
10.000 19.200 4.600 6.500
SECOND ––
4.600 9.800 2.200 3.400
HOUR ––
4.600 10.300 2.400 4.300
QCDSET
SD memory card to standard ROM
690.800 736.470 1146.900 1179.500
Standard ROM to SD memory card
6981.400 7232.070 5613.900 5653.500
DATERD ––
4.600 11.200 2.500 4.200
DATEWR ––
6.500 19.300 4.100 8.900
DATE +
No digit increase
10.000 19.400 4.700 6.600
Digit increase
9.900 19.700 4.600 6.500
S.DATERD ––
7.800 22.500 4.800 7.100
S.DATE +
No digit increase
15.100 34.100 7.400 10.000
Digit increase
15.000 34.100 7.400 10.000
S.DATE -
No digit increase
13.700 33.600 7.400 10.300
Digit increase
13.700 33.600 7.500 10.200
PSTOP ––
67.600 104.100 56.600 79.800
POFF ––
66.800 103.600 57.200 79.800
PSCAN ––
67.900 104.800 60.100 79.900
WDT ––
1.600 4.800 1.100 2.400
DUTY ––
4.900 10.100 4.800 9.600
TIMCHK ––
4.100 9.100 3.500 4.700
ZRRDB File register of standard RAM
2.900 3.300 1.800 2.100
ZRWRB File register of standard RAM
3.600 3.800 2.400 2.700
ADRSET ––
2.200 4.800 2.100 2.600
ZPUSH ––
8.000 12.000 5.800 7.500
ZPOP ––
8.200 10.900 5.800 6.400
S.ZCOM
When mounting CC-Link module
(Master station side)
23.700 48.500 19.300 26.000
When mounting CC-Link module
(Local station side)
23.700 48.500 19.100 26.200
When mounting CC-Link IE Field
Network module (Master station side)
31.500 72.000 31.000 58.000
When mounting CC-Link IE Field
Network module (Local station side)
31.500 72.000 31.000 58.000
S.RTREAD ––
8.500 27.000 7.400 19.000
S.RTWRITE ––
9.000 28.000 8.300 19.800
UNIRD n1 n2
n2 = 1
5.000 14.100 3.700 8.000
n2 = 16
13.600 22.600 12.200 16.600
TYPERD ––
32.100 67.600 29.500 52.500
TRACE Start
58.100 58.100 43.800 44.700
TRACER ––
6.100 6.100 4.500 4.500
UMSG
Number of displayed characters = 1
7.300 17.000 7.000 13.500
Number of displayed characters = 32
16.500 26.300 14.300 21.300
SP.FWRITE ––
81.000 81.800 63.500 64.100
SP.FREAD ––
81.100 81.700 61.600 62.500
SP.DEVST ––
50.100 50.100 39.400 39.400
S.DEVLD ––
12.000 27.600 10.000 17.000
