8 - 59
8. DEBUGGING FUNCTION
(1) Make the settings on the simulation setting screen shown below.
• The following shows details on the settings that can be made for each item:
Setting Item Setting Option Description
Input Refresh Yes/No
Select whether inputs from external sources are input
to the CPU module or not.
Output Refresh Yes/No
Select whether the operation results in the CPU
module are output to external destinations or not.
Link Memory/
Buffer Memory
Access Unit
Ignore
Depend on Simulation
Data File
Select the method of accessing each module.
To Next Page
