16. POWER SUPPLY MODULE
REMARK
1) The number of occupied slots for the A66P is 1.
Applicable wire size
0.75 to 2mm
2
Applicable solderless
terminal
R1.25-4, R2-4
RAV1.25, RAV2-4
R1.25-3, R2-3
RAV1.25-3,
RAV2-3
R1.25-4, R2-4
RAV1.25-4,
RAV2-4
Applicable tightening
torque
78 to 118N cm 39 to 59N cm
78 to
118N cm
External dimensions
250(H)mm (9.8inch) 55(W)mm (2.1inch) 121(D)mm (4.7inch)
250(H)mm
(9.8inch)
37.5(W)mm
(1.5inch)
121(D)mm
(4.7inch)
250(H)mm
(9.8inch)
55(W)mm
(2.1inch)
121(D)mm
(4.7inch)
Weight 0.98 kg
0.75 kg
0.94 kg 0.8 kg 0.94 kg 0.75 kg 0.8 kg
Allowable momentary
power failure period
*3
20ms or less 1ms or less 20ms or less –
20ms or less
(at 100V DC)
Item
Specifications
A61P A61PN A62P A63P A65P A66P A67P
