Mitsubishi Q2ACPU User Manual

16 - 3
16. POWER SUPPLY MODULE
(2) CE-compliant power supply module
Power supply module specifications
Item
Performance specifications
A61PEU A62PEU
Slot position Power supply module slot
Input power supply 100 to 120/200 to 240VAC +10%/-15%
Input frequency
50/60Hz 5%
Input voltage distortion Within 5% (See Section 19.8)
Max. input apparent power 130VA 155VA
Inrush current
20A, 8ms or less
*4
Rated output current
5VDC 8A 5A
24VDC
– 0.8A
Overcurrent
protection
*1
5VDC 8.8A or higher 5.5A or higher
24VDC
– 1.2A or higher
Overvoltage
protection
*2
5VDC 5.5 to 6.5V –
24VDC –
Efficiency 65% or higher
Dielectric withstand
voltage
Between
primary side
and FG
2830V AC rms/3 cycles (altitude 2000m (6562ft.))
Noise durability
Checked by noise simulator of noise voltage IEC801-4, 2kV, 1500Vp-p,
noise width 1 s, and noise frequency 25 to 60Hz
Power indicator LED indication of power supply
Terminal screw size
M4 0.7 6
Applicable wire size
0.75 to 2mm
2
Applicable solderless terminal RAV1.25-4, RAV2-4
Applicable tightening torque
98 to 137N cm
External dimensions
250(H)mm (9.8inch) 55(W)mm (2.1inch) 121(D)mm (4.7inch)
Weight 0.8 kg 0.9 kg
Allowable momentary power failure
period
*3
20ms or less
